Description
INNALABS GI-CVG-U1100A Gyroscope
|
Dimensions
|
Parameters
|
GI-CVG-U2x00A/D
|
GI-CVG-U1x00A/D
|
![]() |
Grade
|
Tactical
|
Industrial
|
|
Number of Axes
|
1 or 2
|
||
|
In-run Bias Stability (room temperature, 1σ), deg/hr
|
<0.22 | ||
|
Bias Stability (full temperature range, 1σ), deg/hr
|
< 10
|
< 50
|
|
|
Scale factor error, full temperature range, 1σ
|
< 3,500
|
||
|
Angular Random Walk, deg/√hr
|
0.01 typical
|
||
|
Electrical Interface
|
|
||
|
Bandwidth (-3dB)
|
≥ 300
|
||
|
Interface
|
Analogue or Digital RS-422
|
||
|
Start-up Time
|
1 sec typical
|
||
|
Physical Specifications
|
|
||
|
MTBF
|
>500,000
|
||
|
Weight
|
1.1 kg (One-Axis)
1.2 (Two-Axis)
|
||
|
Dimensions
|
H68 x L107 x W107 mm
|
||
|
Built-in Self Test
|
Yes
|
||
